Motorized Curtain & Blind Systems
Applications
Hotels & Luxury Resorts
Conference Rooms
Modern Homes
Office Spaces
Residential Villas
Key Highlights
✓ 30dB Ultra-Quiet Operation – Advanced patented silent technologies
✓ Intelligent Memory Function – Power-failure protection with automatic position saving
✓ WiFi/Zigbee/Bluetooth Compatible – Smart home integration ready
✓ Multiple Motor Series Available – AM75, AM95, AM68, AM50 options
✓ Energy Efficient Design – Thermal insulation and cost reduction
✓ 40% Extended Lifespan – Memory function increases track system durability
Motorized Curtain Solution
Introduction
Motorized curtain systems represent a next-generation evolution of manual fabric curtains. Originally designed for large windows, these systems combine exquisite craftsmanship with elegant appearance, making them the preferred choice for hospitality, commercial, and residential applications.
Ideal Applications
- Hotels and luxury resorts
- Meeting rooms and conference halls
- Business centers and corporate offices
- Modern homes and residential apartments
- High-end villas and residences.
System Functions
- Automatic limit setting
- Intelligent soft start and soft stop
- Speed adjustment capability
- Multiple patented silent operation technologies
- Real-time position memory and recall
Core Benefits
- Sun shading and glare reduction
- Thermal insulation and energy efficiency
- Privacy control
- Professional appearance
- Create relaxing and comfortable living environments with intelligent automation
System Components & Architecture
Primary Components
- Curtain Motor – Central driving unit with advanced automation
- Master Gearbox – Power transmission component
- Driving Belt – Transfer mechanism
- Pulley – Rotational support structure
- Curtain Track – Guide rail for smooth fabric movement
- Carrier – Fabric support structure
- Concealed Ceiling Bracket – Professional mounting hardware
- Side Bracket – Lateral support
Primary Components
- Fix Holder – Securing mechanism
- Sub Gearbox – Secondary power transmission
Optional Components
- Smart Speaker Integration – Voice control compatibility
- Stretchable Track System – Adjustable sizing feature
- Smart Expansion Rail – Flexible dimension adjustment for AM50 Series
Core Features
- Flexible, Super Silent Design
- Stroke Memory Function (Even During Power Off)
- Touch-To-Go Technology
- Stop On Block Protection
- Memory Function (Intelligent Positioning)
- Fabric Rebound Journey Correction
- Third Limit Position
- Speed Adjustable
- Support For Multiple Motors Online
- Various Control Options
Product Series Specifications
AM75-1.5/100-EM-P
- Type: AC Strong Electric Quiet Curtain Motor
- Torque: 1.5 N·m | Speed: 16 cm/s
- Motor Size: 316×68×53 mm | Power: 66W
- Functions: Touch to go, strong electric central control
AM75-1.5/100-EM-OP
- Type: Central Control Enhanced
- Torque: 1.5 N·m | Speed: 16 cm/s
- Power: 66W | Functions: Central control, flexible operation
AM75-1.5/100-EM-GP
- Type: Speed Adjustable Quiet Motor
- Torque: 1.5 N·m | Speed: 16 cm/s
- Power: 66W | Functions: Speed adjustable, quiet operation
AM95-1/100-ML-P
- Type: AC Magnetic Levitation Motor
- Torque: 1.0 N·m | Speed: 16 cm/s
- Motor Size: 215.5×96×56 mm | Power: 96W
- Functions: Touch to go, magnetic levitation technology
AM95-1/100-ML-GP
- Type: Group Control Variant
- Torque: 1.0 N·m | Speed: 16 cm/s
- Motor Size: 215.5×95×60 mm | Power: 96W
- Functions: Stop on block, speed adjustable, group control
AM95-1/100-ES-E
- Type: AC Flexible Silent Motor
- Torque: 1.0 N·m | Speed: 16 cm/s | Power: 96W
- Functions: Flexible, silent operation
AM68-1/100-EQ-P | Torque: 1.0 N·m | Speed: 16 cm/s | Power: 72W
AM68-1/100-EQ-GP | Torque: 1.0 N·m | Speed: 16 cm/s | Motor: 316×80mm | Power: 72W | Feature: Group control
AM68-1.5/100-EM-QP | Torque: 1.5 N·m | Speed: 16 cm/s | Motor: 316×66×50mm | Power: 65W | Feature: Middle limit
AM68-1.5/100-EM-P | Torque: 1.5 N·m | Speed: 16 cm/s | Motor: 315×68×50mm | Power: 65W
AM68-1.5/80-EM-GP | Torque: 1.5 N·m | Speed: 12 cm/s | Motor: 315mm | Power: 68W | Feature: Double battery
AM68-2/80-EC-P | Torque: 2.0 N·m | Speed: 12 cm/s | Power: 65W | Feature: No clutch
AM68-2/80-EM-GP | Torque: 2.0 N·m | Speed: 12 cm/s | Motor: 315mm | Power: 65W | Feature: Group control
AM68-2/80-EM-P | Torque: 2.0 N·m | Speed: 12 cm/s | Motor: 316×68×53mm | Power: 68W
Base Model Specifications:
- Torque: 1.2 N·m
- Speed: 12 cm/s
- Motor Size: 320×50×50 mm
- Safe Rated Load: 75 kg
- Voltage: AC 100–240V, 50/60Hz
- Rated Power: 65W
- Protection Class: IP44
Smart Connectivity Options:
- WiFi Model (AM50-1.2/100-EM-PW)
- Wireless control via WiFi network
- Smartphone app remote operation
- Zigbee Model (AM50-1.2/100-EM-PZ)
- Zigbee smart home ecosystem support
- Low-power mesh network communication
- Bluetooth Model (AM50-1.2/100-EM-PB)
- Direct Bluetooth connection
- Smartphone app control within range
Core Functions:
- Adjustable running speed
- Stop on block protection
- Multiple control interfaces
- RF remote control compatibility
- APP central control with two-way communication
- Real-time status feedback
- Automatic memory on first power-on
- Position retention after power failure
- Manual operation when power off
- Fabric rebound journey correction
Smart Expansion Rail Technology:
- Freely stretchable in various dimensions
- No measurement required before installation
- Eliminates measurement deviation issues
- Saves installation time and costs
- Reduces rework from cutting deviations
- Three noiseless technologies (noise <30 dB)
Control Options & Smart Integration
Wireless Remote Control
- RF (radio frequency) based operation
- Range-dependent remote activation
- Multiple units capable
- User-friendly handheld emitters
Wired Wall Switch Control
- Direct connection via wiring
- Permanent installation option
- Dry contact switch support
- Multiple switch locations possible
RS232/RS485 Serial Communication
- Professional-grade protocol
- Computer system integration
- Advanced automation capability
- Long-distance transmission
APP Central Control Features
Technical Specifications
Electrical Specifications
- Voltage: AC 100–240V (standard)
- Frequency: 50/60 Hz
- Protection Class: IP44 (dust and splash resistant)
Performance Specifications
- Noise Level: 30 dB or lower (all series)
- Torque Range: 1.0–2.0 N·m (depending on model)
- Speed Range: 12–16 cm/s (adjustable based on model)
- Power Consumption: 65–96W (depending on model)
Mechanical Specifications
- Load Capacity: Up to 75 kg per motor
- Temperature Range: Standard industrial range
- Duty Cycle: Continuous operation capable
- Standard Interfaces: External switch support, multi-motor capability, computer integration ready
Motorized Sheer Specifications
Fabric Characteristics
- Material: 100% Polyester Fiber Cloth
- Structure: Double-layer gauze with inner polyester curtain
- Weight: Standard density for durability
Protective Treatments
- Anti-static coating
- Dust-proof treatment
- Anti-fouling protection
- Anti-mildew resistant
- Optional: flame retardant, anti-ultraviolet, waterproof, anti-oil, antibacterial
Light Control Options
- Semi-transparent (light-transmitting type)
- Full shading (complete blocking type)
Why Choose These Systems?
Advanced Technology
- Advanced silent operation (≤30 dB)
- Intelligent memory functions
- Multiple safety features
- Flexible control options
Professional Quality
- Professional design
- Energy efficiency
- Extended durability (40% longer lifespan)
- Multiple patented technologies
